XML and RegEx again...

Today I was thinking about XML and RegEx...You can parse an XML document using RegEx, not the best way, but surely is fun...so...what about creating an XML file using RegEx? More fun for sure! -:D Of course...and just to make it clear...there are other more standard and easier ways to achieve the same: Simple Transformations, XLST Transformation y XML DOM.

But as always...this code was very fun to made -;)

TYPES: BEGIN OF TY_XML,
       FIELD TYPE STRING,
       END OF TY_XML.

DATA: T_DD03P_TAB  TYPE STANDARD TABLE OF DD03P,
      T_FILETAB TYPE FILETABLE,
      T_XML TYPE STANDARD TABLE OF TY_XML.

DATA: L_FLAG TYPE C,
      L_AUX TYPE STRING,
      L_STRING TYPE STRING,
      L_XML_LINE TYPE STRING,
      DATA_TAB TYPE REF TO DATA,
      SIZE TYPE I,
      W_SUBRC TYPE SY-SUBRC,
      W_FILE_OUT TYPE STRING.

FIELD-SYMBOLS:  TYPE STANDARD TABLE,
                TYPE ANY,
                TYPE ANY,
                LIKE LINE OF T_XML,
                LIKE LINE OF T_DD03P_TAB,
                LIKE LINE OF T_FILETAB.

SELECTION-SCREEN BEGIN OF BLOCK TEST WITH FRAME.
PARAMETERS:
           TABNAME TYPE DD02L-TABNAME,
           FILE_OUT LIKE RLGRAP-FILENAME.
SELECTION-SCREEN END OF BLOCK TEST.

START-OF-SELECTION.
  PERFORM VALIDATE_TABLE USING TABNAME
                         CHANGING L_FLAG.
  IF L_FLAG EQ SPACE.
    PERFORM LOAD_TABLE_STRUCT USING TABNAME.
    PERFORM LOAD_TABLE_INFO USING TABNAME.
    PERFORM CREATE_XML.
    PERFORM DOWNLOAD_XML.
  ENDIF.

AT SELECTION-SCREEN ON VALUE-REQUEST FOR FILE_OUT.
  CALL METHOD CL_GUI_FRONTEND_SERVICES=>FILE_OPEN_DIALOG
    EXPORTING
      WINDOW_TITLE     = 'Seleccionar archivo'
      DEFAULT_FILENAME = '*.xml'
      FILE_FILTER      = '*.xml'
    CHANGING
      FILE_TABLE       = T_FILETAB
      RC               = W_SUBRC.

  READ TABLE T_FILETAB INDEX 1
  ASSIGNING .
  FILE_OUT = .
  W_FILE_OUT = FILE_OUT.

  IF FILE_OUT IS INITIAL.
    EXIT.
  ENDIF.

*&------------------------------------------------------*
*&      Form  VALIDATE_TABLE                            *
*&------------------------------------------------------*
FORM VALIDATE_TABLE USING P_TABNAME
                    CHANGING P_FLAG.

  SELECT SINGLE TABNAME
  INTO P_TABNAME
  FROM DD02L
  WHERE TABNAME EQ P_TABNAME.
  IF SY-SUBRC NE 0.
    P_FLAG = 'X'.
  ELSE.
    CLEAR P_FLAG.
  ENDIF.

ENDFORM.                    " VALIDATE_TABLE

*&------------------------------------------------------*
*&      Form  LOAD_TABLE_STRUCT                         *
*&------------------------------------------------------*
FORM LOAD_TABLE_STRUCT USING P_TABNAME.

  CALL FUNCTION 'DDIF_TABL_GET'
    EXPORTING
      NAME          = P_TABNAME
    TABLES
      DD03P_TAB     = T_DD03P_TAB
    EXCEPTIONS
      ILLEGAL_INPUT = 1
      OTHERS        = 2.

ENDFORM.                    " LOAD_TABLE_STRUCT

*&------------------------------------------------------*
*&      Form  LOAD_TABLE_INFO                           *
*&------------------------------------------------------*
FORM LOAD_TABLE_INFO USING P_TABNAME.

  CREATE DATA DATA_TAB TYPE STANDARD TABLE OF (P_TABNAME).
  ASSIGN DATA_TAB->* TO .
  SELECT *
  FROM (P_TABNAME)
  INTO TABLE .

ENDFORM.                    " LOAD_TABLE_INFO

*&------------------------------------------------------*
*&      Form  CREATE_XML                                *
*&------------------------------------------------------*
FORM CREATE_XML.

  APPEND INITIAL LINE TO T_XML ASSIGNING .
  -FIELD = ''.
  APPEND INITIAL LINE TO T_XML ASSIGNING .
  -FIELD = ''.
*XML Logic here!
  LOOP AT  ASSIGNING .
    L_XML_LINE = ''.
    LOOP AT T_DD03P_TAB ASSIGNING .
      ASSIGN COMPONENT -FIELDNAME OF
      STRUCTURE  TO .
      L_AUX = .
      CONDENSE L_AUX NO-GAPS.
      CONCATENATE -FIELDNAME '/' L_AUX
      INTO L_STRING.
      REPLACE REGEX '(\w+)[\/](\w+)' IN L_STRING
      WITH '<$1>$2'.
      CONCATENATE L_XML_LINE L_STRING INTO L_XML_LINE.
    ENDLOOP.
    APPEND INITIAL LINE TO T_XML ASSIGNING .
    -FIELD = L_XML_LINE.
    CONCATENATE -FIELD ''
    INTO -FIELD.
  ENDLOOP.
*XML Logic here!
  APPEND INITIAL LINE TO T_XML ASSIGNING .
  -FIELD = ''.

ENDFORM.                    " CREATE_XML

*&------------------------------------------------------*
*&      Form  DOWNLOAD_XML                              *
*&------------------------------------------------------*
FORM DOWNLOAD_XML.

  CALL METHOD CL_GUI_FRONTEND_SERVICES=>GUI_DOWNLOAD
    EXPORTING
      BIN_FILESIZE = SIZE
      FILENAME     = W_FILE_OUT
      FILETYPE     = 'DAT'
    CHANGING
      DATA_TAB     = T_XML.

ENDFORM.                    " DOWNLOAD_XML

Greetings,

Blag.
